Product Details
- Place of Origin: China
- Brand Name: HJ
- Model Number: HS-7085A, HS-7200A, HS-7320A, HS-7500A
Video Presenter Specification
| Model(HS-) | 7085A | 7200A | 7320A | 7500A |
| Camera Section | ||||
| Active Pixel | 850k | 2000k | 3200k | 5000k |
| Horizontal TV Line | 700 | 800 | 900 | 1000 |
| Noise-signal Ratio (DB) | 50 | |||
| Covering Power | The above A4 format | |||
| Brightness Control | Yes | |||
| Sharpness Adjustment | Yes | |||
| Color Conditioning | Yes | |||
| White Balance | Yes | |||
| Black and White/ Color Conversion | Yes | |||
| Positive and Negative Film | Yes
| |||
| Same Screen Contrast | Yes | |||
| Image Freezing | Yes | |||
| Image Mirroring | Yes | |||
| Factory Setting | Yes | |||
| Optical | ||||
| Focusing Method | Automatic, manual, tracking focus | |||
| Iris Disphragm | Automatic | |||
| Optical Zoom | ≥22times(*) | |||
| Electronic Zoom | ≥10times | |||
| Lighting Part | ||||
| Top Light | 3W*2LED | |||
| Bottom Lamp | 1W LED lamp | |||
| RGB/HV Input | 1 way (optional 2 road) | |||
| RGB/HV Out Put | 1 way (optional 2 road) | |||
| HDMI Input | Optional 2 road | |||
| HDMI Out Put | Optional 1 | |||
| Video Input (RCA) | 1 | |||
| Video Output (RCA) | 1 | |||
| Audio 3.5 Input | 2 way (optional 3) | |||
| Audio 3.5 Output | 1 | |||
| RS232 Communication Port | 1 | |||
| USB | 1(obligate) | |||
| Service Condition(s) | ||||
| Ambient Temperature | 0℃-50℃ | |||
| Ambient Humidity | 20%-80% | |||
| Other Conditions | No vibration and no pollution | |||
| Overall Unit | ||||
| Electric Source | External power adapter, 5V DC power supply | |||
| Maximum Power Dissipation | 10W | |||
| Light Box Size | 150mm×110mm | |||
| Working Dimension(l×t×h) | 410mm×320mm×490mm | |||
| Folding Size(l×t×h) | 410mm×320mm×135mm | |||
| Appendix | Power adapter, VGA cable, manual, warranty, card, certificate | |||
| Matching Function | ||||
| Image Storage | Optional | |||
| USB Image Communication Port | Optional | |||
| Remote Control | Optional, built-in | |||
